Description
|
Maximum output power |
300W |
|
Welding mode |
Large spot welding（f0.8mm） |
|
Cooling method |
Air cooling |
|
Equipment dimensions |
550mm*415mm*190mm |
|
Equipment weight |
25kg |
|
Power supply requirements |
220V/10A |
|
Temperature for operating ambient
|
0℃ - 55 ℃ |
|
Indicator light |
Red |
|
Working mode |
Continuous wave |
|
Polarization direction |
Random |
|
Power regulation range |
10%- 100% |
|
Output fiber core diameter |
220 µm |
|
Wavelength range |
973±5nm |
|
Output power stability |
<3%（24 h） |
|
Specification of protective mirror |
25mm*2mm |
|
Focal length of output mirror |
135mm |
|
Fiber length |
3m |
1. Low power consumption: high electro-optic conversion rate, 50% reduction in energy consumption, 220V / 10A power supply, arbitrary matching household / factory
2. Conducted air-cooling: green energy saving, no condensation in summer and no freezing in winter
3. High cost-performance ratio: low price, which greatly improves the cost-performance ratio of products
4. Large light spot welding: the weld is firm and beautiful, bringing users efficient and perfect welding scheme
5. High temperature resistance: new cooling technology ensures that the equipment can work at 0-55 ℃
